Security Glass
GAFFCO Security Glass Clad Laminates provide long-lasting protection against moderate ballistic and forced entry threats. The durability and versatility of these laminates make them a perfect choice for correctional facilities, courthouses, government buildings and corporate security applications. By altering thickness and composition, such as adding layers of glass or polycarbonate, GAFFCO Security Glass Clad Laminates can be customized to meet your requirements for specific threat levels.
We also manufacture laminates to meet your specific threat or standards specifications. Please call with your requirements.
Available Surfaces and Colors:
- Tempered
- Heat Strengthened
- Annealed
- Chemically Strengthened
- Clear, Grey, Green or Bronze Tints
Diagrams
Specifications
| Product | Threat | Thickness | Lbs/Sq.Ft. |
|---|---|---|---|
| GAFF GCP 375 | Forced Entry | .375" | 4.00 |
| GAFF GCP 450 | .38 Special, Forced Entry | .450" | 4.40 |
| GAFF GCP 530 | .38 Special, Forced Entry | .530" | 4.79 |
| GAFF GCP 600 | .38 Special, Forced Entry | .600" | 5.18 |
| GAFF GCP 625 | 9 mm, Forced Entry | .625" | 5.28 |
| GAFF GCP 725 | 9 mm, Forced Entry | .725" | 5.96 |
| GAFF GCP 750 | 9 mm, .357 MAG, Forced Entry, 30 Minute Physical Attack | .750" | 6.06 |
| GAFF GCP 875 | .357 MAG, Forced Entry, 60 Minute Physical Attack | .875" | 7.14 |
| GAFF GCP 960 | .357 MAG, Forced Entry, 60 Minute Physical Attack | .960" | 7.30 |
| GAFF GCP 1000 | .357 MAG, Forced Entry, 60 Minute Physical Attack | 1.000" | 9.33 |
| GAFF GCP 1250 | .44. MAG, Forced Entry, 60 Minute Physical Attack | 1.250" | 10.50 |
